Applicable industries and materials
◇ Furniture: cabinets, wardrobes, panel furniture, solid wood furniture, office furniture, wooden
doors.
◇ Wood products: speakers, game cabinets, computer tables, sewing machines, musical instruments.
◇ Sheet processing: insulation, plastic parts, motor car body, bowling track, epoxy resin and other
compounds.
◇Decoration industry: Acrylic, PVC, MDF, plexiglass, plastic, and copper and aluminum and other soft
metal plate engraving and milling cutting.
Parameters Table
有效行程范围 | 2500×1260×200mm |
最大加工尺寸 Process size | 2440×1240×200mm |
台面尺寸 Stroke | 2500×1250mm |
传动形式Transmission | X/Y/Z丝杠(Wire rod) |
台面结构 Table structure | 双层台面真空吸附 (Double surface vacuum adsorption） |
主轴功率 Spindle Power | 9KW（Ltaly）意大利原装 |
主轴转速 Max Spindle Speed | 24000r/min |
快移速度Max Speed | 70m/min |
最大工作速度 Max Working speed | 52m/min |
刀库形式 Bamboo hat type knife | 斗笠式（The bamboo hat）伺服刀库 |
刀库容量 Knife library capacity | 12 |
驱动系统 Drive system | 安川（yaskawa） |
工作电压Working voltage | AC380/3PH/50HZ |
操作系统Operating system | 新代（Taiwan SYNTEC） |
上料方式Feeding method | 自动automatic |
整机重量Weight | 3800KG
|
